2500W Tave Sine Wave Inverter kanthi Charger HK200PC

Model:HK2500PC

Minangka Professional Pabrik, kita pengin nyedhiyakake kualitas dhuwur gelombang murni 2500W kanthi pangisi daya hk2500pc. Lan kita bakal nawarake layanan sawise sale lan kiriman pas wektune.

Kirim Pitakonan Unduh PDF

Deskripsi Produk

Ing ngisor iki minangka introduksi saka gelombang gelombang murni 2500W kanthi biaya pangisian HK2500pc, ngarep-arep bisa mbantu luwih ngerti babagan pangisi daya iki. Sugeng pelanggan anyar lan lawas supaya terus kerja bareng karo kita kanggo nggawe masa depan sing luwih apik!

Fitur:

● output gelombang sine (thd <5%)

● Power ON / OFF SWITCH

● Eficiency dhuwur nganti 92%

● Breacer sirkuit AC lan AC AC

● Transfer wektu kurang saka 16ms

● usb: 5v /2.1a / jinis c: maks 35w

● Komunikasi Rs-485

● Input & output isolasi kanthi lengkap

● Proteksi input: polaritas mbalikke (sekring) / ing voltase / liwat voltase.

● Perlindungan Output: Circuit cendhak / Overload / Suhu / Liwat Voltase

Model		HKC2500p-112	HKC2500p-124	HKC2500p-212	HKC2500p-224
Mode inverter
Input	Voltase normal	12VDC	12VDC	12VDC	12VDC
	Range Voltase Input (± 0.5v)	10.8 ~ 16VDC	21.6 ~ 32.0VDC	10.8 ~ 16VDC	21.6 ~ 32.0VDC
	Perlindungan voltase input (± 0.5v)	16VDC	32vdc	16VDC	32vdc
	Perlindhungan voltase input (± 0.5v)	10VDC	20vdc	10VDC	20vdc
	Peringatan voltase input (± 0.5v)	10.8VDC	21.6VDC	10.8VDC	21.6VDC
	Ora ana saiki	<0.72A	<0.36A	<0.72A	<0.36A
Output	Terminal Kontrol Remot	2500W ± 5%
	Daya Surge	Mbukak 5000w (2 detik)
	Frekuensi	50 / 60Hz ± 1Hz (Pabrik)
	Voltase output	100/110/115 / 120vac ± 10%		200/220/230 / 240vac ± 10%
	Min.Efficiency (Full Full Load)	89%	89%	89%	89%
	Formulir gelombang output	Gelombang sine murni (thd <5%)
Perlindhungan	0 ~ + 60 ℃	Liwat / ing voltase, polaritas mbalikke (sekring internal)
	Perlindungan output AC	Short-circuit, Overload
	Perlindungan input AC	30 amp sirkuit becer		16 Ampir Breaker Breaker
	Perlindhungan suhu	Mati
Mode pangisi daya
Input AC	Terminal Kontrol Remot	110vac, 50 / 60Hz (setelan kanthi pabrik)		230vac, 50 / 60Hz (setelan kanthi pabrik)
	Range Voltase Input	90 ~ 130vac		Relay spesmifikasi
	Rangkaian Frekuensi Input	50hz: 47 ~ 53hz / 60Hz: 57 ~ 63 Hz
	Efisiensi (Max.)	> 88%
	Koreksi faktor tenaga (pfc)	> 0.95 (maksimal)
Output dc	Ngisi daya saiki	Max.40a	Max.20a	Max.40a	Max.20a
	Voltase max.utput	14.4VDC	28.8VDC	Max.14.4vdc	Max.28.8cdc
	Kontrol Baterei (Charger Baterai 3 Tahap)	Akeh / Penyerapan / Ngambang
Sinyal lan Kontrol	Panel Kontrol Remot (Opsional)	Tampilan LCD
	Terminal Kontrol Remot	RS485
	Tampilan LCD	voltase, wattage
	Relay spesmifikasi	30 sistem amp / 120vac @ 110v		16amp / 250vac @ 230V
Lingkungan
Suhu Kisaran	Beban kebak	0 ~ + 40 ℃; 5 ℃ @ 70% beban daya
	Panyimpen	0 ℃ ~ 70 ℃
Range asor		Max93%, ora kondensasi
Kelangan		Suhu & Muja Ngatur Pendhemen Pendhaftaran
Liyane	Dimensi (w × h × d)	439 × 252 × 88mmmm
	Bobot	7.2kg
	Port komunikasi	Konektor jinis RS-485 (RJ-11), Ethernet (opsional)
