500W gelombang sine murni kanthi pangisi daya hk500pc

Model:HK500PC

HKC1500P-224

Kirim Pitakonan Unduh PDF

Deskripsi Produk

Ing ngisor iki yaiku introduksi inverter gelombang murni murni sing berkualitas tinggi, ngarep-arep bisa mbantu 500W inverter sine murni kanthi pangisi daya hk500pc. Sugeng pelanggan anyar lan lawas supaya terus kerja bareng karo kita kanggo nggawe masa depan sing luwih apik!

Fitur:

● output gelombang sine (thd <5%)

● Power ON / OFF SWITCH

● Eficiency dhuwur nganti 92%

● Breacer sirkuit AC lan AC AC

● Transfer wektu kurang saka 16ms

● usb: 5v /2.1a / jinis c: maks 35w

● Komunikasi RS-485.

● Input & output isolasi kanthi lengkap

● Proteksi input: mundur polaritas (sekring) / ing voltase / liwat voltase

● Perlindungan Output: Circuit cendhak / Overload / Suhu / Liwat Voltase

Model		HKC500p-112	HKC500p-124	HKC500p-212	HKC500p-224
Mode inverter
Input	Voltase normal	12VDC	12VDC	12VDC	12VDC
	Range Voltase Input (± 0.5v)	10.8 ~ 16VDC	21.6 ~ 32.0VDC	10.8 ~ 16VDC	21.6 ~ 32.0VDC
	Perlindungan voltase input (± 0.5v)	16VDC	32vdc	16VDC	32vdc
	Perlindhungan voltase input (± 0.5v)	10VDC	20vdc	10VDC	20vdc
	Peringatan voltase input (± 0.5v)	10.8VDC	21.6VDC	10.8VDC	21.6VDC
	Ora ana saiki	<0.4a	<0.3A	<0.4a	<0.3A
Output	Terminal Kontrol Remot	500W ± 5%
	Daya Surge	Beban 1000w (2 detik)
	Frekuensi	50 / 60Hz ± 1Hz (Pabrik)
	Voltase output	100/110/115 / 120vac ± 10%		200/220/230 / 240vac ± 10%
	Min.Efficiency (Full Full Load)	89%	89%	89%	89%
	Gelombang Output	Gelombang sine murni (thd <5%)
Perlindhungan	0 ~ + 60 ℃	Liwat / ing voltase, polaritas mbalikke (sekring internal)
	Perlindungan output AC	Short-circuit, Overload
	Perlindungan input AC	30 amp sirkuit becer		16TART SIRCUIT BREAKER
	Perlindhungan suhu	Mati
Mode pangisi daya
Input AC	Terminal Kontrol Remot	110vac, 50 / 60Hz (setelan kanthi pabrik)		230vac, 50 / 60Hz (setelan kanthi pabrik)
	Range Voltase Input	90 ~ 130vac		Relay spesmifikasi
	Rangkaian Frekuensi Input	50hz: 47 ~ 53hz / 60Hz: 57 ~ 63 Hz
	Efisiensi (Max.)	> 88%
	Koreksi faktor tenaga (pfc)	> 0.95 (maksimal)
Output dc	Ngisi daya saiki	Max.10a	Max.5A	Max.10a	Max.5A
	Voltase max.utput	14.4VDC	28.8VDC	Max.14.4vdc	Max.28.8cdc
	Kontrol Baterei (Charger Baterai 3 Tahap)	Akeh / Penyerapan / Ngambang
Sinyal lan Kontrol	Panel Kontrol Remot (Opsional)	Tampilan LCD
	Terminal Kontrol Remot	RS485
	Tampilan LCD	voltase, wattage
	Relay spesmifikasi	30 sistem amp / 120vac @ 110v		16amp / 250vac @ 230V
Lingkungan
Suhu Kisaran	Beban kebak	0 ~ + 40 ℃; 5 ℃ @ 70% beban daya
	Panyimpen	0 ℃ ~ 70 ℃
Range asor		Max93%, ora kondensasi
Kelangan		Suhu & Muja Ngatur Pendhemen Pendhaftaran
Liyane	Dimensi (w × h × d)	309 × 182 × 87mm
	Bobot	2.6Kg
	Port komunikasi	Konektor jinis RS-485 (RJ-11), Ethernet (opsional)
